In Hydraulic and Oil Pressure Scenarios, Service Life Is Often Lost to Pulsation and Shock

In hydraulic stations, oil pressure control, and engineering equipment, when people discuss how long a pressure transmitter can be used, the most easily overlooked factor is instantaneous peaks. The system nominal pressure may not be high, but obvious impact can occur during start-stop, reversing, and unloading. This kind of impact is not friendly to the diaphragm and internal electronic components.

Such scenarios are not suitable for selecting models based only on working pressure. A more stable approach is to combine peak pressure margin and overload capacity. A common practice in industrial sites is to let the overload pressure reach about twice the full-scale range, and then match it with a damping hole, snubber tube, or anti-vibration installation; service life is usually more guaranteed.

If the Medium Is Clean, Service Life Depends More on Structural Match

If the cleanliness of the oil or hydraulic medium is relatively high, the sensor body may not fail first; instead, loose joints, cable fatigue, and vibration transmission may cause signal fluctuations. Especially near pump sets, if the installation position is too close to the vibration source, service life will be significantly reduced.

For general-purpose products like Domestic General Pressure Transmitter PTS614 Hydraulic Oil Pressure Gas Pressure Sensor, the measuring range can be selected within -0.1~100MPa, and outputs such as 4-20mA and 0-5V are supported. If used in oil pressure or hydraulic systems, the key is not only whether the parameters are sufficient, but also whether the interface type, power supply conditions, and anti-vibration installation are considered together.

In Gas Pressure and Compressed Air Systems, It Looks Light-Duty, but It Is Actually More Afraid of Condensed Water

Many sites assume that gas pressure systems have “light media and low pressure,” so the default service life will be longer. In reality, pressure transmitters are used for a long time, but in gas measurement they are often defeated by condensed water, oil mist, and particulate impurities. Especially at the end of compressed air systems, when there is a large day-night temperature difference, the signal end and pressure inlet may both be affected by moisture.

If compressed air treatment is not sufficient and the diaphragm surface is contaminated for a long time, zero drift and response lag will gradually appear. The focus here is not pursuing high precision blindly, but ensuring drainage, filtration, installation orientation, and electrical sealing are in place. The choice of waterproof connectors, aviation plugs, or Hirschmann connectors will also directly affect long-term stability.

In Chemical and High-Temperature Media Scenarios, First Check Compatibility, Then Talk About Accuracy

In chemical, environmental protection, pharmaceutical, or metallurgical processes, pressure transmitters are used for a long time and usually cannot be discussed separately from the medium itself. No matter how suitable the pressure range is, if the medium is unfriendly to the diaphragm, sealing parts, or interface material, the equipment service life will be quickly shortened.

In such working conditions, material and temperature compensation are more important than nominal accuracy. 316L stainless steel has relatively good compatibility with many non-corrosive gases and liquids, but when strong corrosion, easy crystallization, or high-viscosity media are encountered, the isolation method, pressure guidance structure, and cleaning cycle still need further confirmation. If the medium temperature approaches the upper limit for a long time, drift caused by heat conduction cannot be ignored.

If there are high-temperature gases, liquids, fluids, or viscous media on site, it is better to prioritize models with temperature compensation, a clearly defined temperature resistance range, and the ability to be installed with thermal isolation. This is more practical than simply choosing the one with the lowest purchase cost. Otherwise, although it may run in the short term, maintenance frequency will obviously increase in the long term.

In Different Applications, the Key Points for Judging Service Life Are Not the Same

Treating similar scenarios as the same requirement is one of the most common misconceptions in service life evaluation. The differences below are often more worth confirming in advance than simply asking whether it can be measured.

• Continuous stable pressure conditions: pay more attention to long-term drift, output stability, and calibration cycle.
• Frequent start-stop conditions: pay more attention to overload capacity, impact resistance, and connector sealing reliability.
• High-temperature pulsating conditions: pay more attention to compensation temperature range, heat dissipation distance, and installation isolation.
• Outdoor humid conditions: pay more attention to waterproof connection, cable outlet, and housing protection.
• Viscous or clog-prone media: pay more attention to interface structure, drain convenience, and cleaning frequency.

If the application spans a large range, it is best to check the measuring range, output, electrical connection, and installation method together during model selection. For example, PTS614 can be selected with threaded installation or flange installation, with interfaces such as M20×1.5, G1/2, and G1/4, and the power supply supports 24VDC and 12-36VDC wide voltage. These details are not additional items in service life judgment, but important conditions that determine the later failure rate.

Many Service Life Problems Actually Come from Installation and Maintenance Details

When discussing how long a pressure transmitter can be used, you cannot look only at the factory parameters. In practice, the more common issue is “selected correctly, installed incorrectly.” For example, mounting the transmitter directly in a position with strong vibration, suspending the cable for a long time under tension, or connecting high-temperature media directly to the body without isolation; these are not problems with the component itself, but they can quickly turn into service life problems.

There are also two easily overlooked points in maintenance. One is only dealing with failures after they occur, without establishing an inspection frequency; the other is only looking at the display value and ignoring zero-point deviation and output fluctuation. The deterioration of pressure transmitters is often gradual; the earlier drift and response abnormalities are discovered, the more likely you are to avoid being forced to replace them during shutdown.
