0–10V vs. 4–20mA Pressure Transmitters: Start with the Signal Transmission Logic

Both 0–10V pressure transmitters and 4–20mA pressure transmitters are used to convert pressure values into standard electrical signals for reading by PLCs, variable frequency drives, data acquisition modules, or intelligent digital display control instruments. Their core difference lies not in the pressure measurement principle, but in the output signal format: the former reflects pressure through voltage changes, while the latter reflects pressure through current changes.

Taking a 0–1.0MPa measuring range as an example, with a 0–10V output, 0MPa normally corresponds to 0V and 1.0MPa corresponds to 10V; with a 4–20mA output, 0MPa corresponds to 4mA and 1.0MPa corresponds to 20mA. The control system can obtain the actual on-site pressure value through linear conversion.

Engineering selection should not be based solely on whether the control cabinet has an analog input. Cable length, electromagnetic environment, power supply conditions, grounding quality, and subsequent maintenance methods must also be considered comprehensively. For industrial automation measurement and control systems, the output method directly affects data stability and troubleshooting efficiency.

Basic Conversion of the Two Output Signals

The calculation for voltage signals is relatively straightforward. When the lower range limit is 0, the actual pressure is approximately equal to the measured voltage divided by 10 and then multiplied by the full scale. For example, if 6.0V is detected, the corresponding pressure is approximately 0.60MPa within a 1.0MPa range.

For current signals, the 4mA zero point must be deducted. The calculation formula can be understood as: actual pressure = (measured current − 4mA) ÷ 16mA × span. If the measured current is 12mA, the corresponding pressure is approximately 0.50MPa within a 0–1.0MPa range.

4mA is not a meaningless starting point, but a “live zero.” When the on-site pressure is zero while the loop still carries 4mA, the control side can distinguish normal zero pressure from abnormal conditions such as wire breaks and power loss. This is also an important reason why 4–20mA is widely used in industrial field applications.

The Value of the Zero Signal for Fault Identification

In a 0–10V system, 0V may indicate zero pressure, but it may also mean that the sensor is not powered, the cable is disconnected, or the input terminal has failed. Further assessment is required in combination with other information. This increases diagnostic difficulty in unattended applications or operating conditions with high safety requirements.

In a 4–20mA loop, values below approximately 3.6mA or above approximately 21mA can generally serve as references for fault assessment. Specific thresholds should be based on the transmitter, PLC module, and system alarm strategy. Setting upper and lower limit alarms can improve the reliability of pressure monitoring.

It should be noted that abnormal current ranges are not completely identical for all products. During procurement and commissioning, the fault output definition, accuracy class, load capacity of the pressure transmitter, and the recognition range of the control system analog module should be confirmed.

Core Differences: Transmission Distance and Interference Resistance

0–10V pressure transmitters are suitable for short-distance, low-interference internal equipment connections, such as small hydraulic power units, test equipment, standalone control cabinets, and compact automation devices. When wiring is short, voltage signals can be read directly and system configuration is relatively simple.

As transmission distance increases, conductor resistance, contact resistance, and external electromagnetic interference can cause voltage attenuation or fluctuations. Especially in environments with dense variable frequency drives, motors, welding machines, and solenoid valves, 0–10V signals are more susceptible to common-mode interference and ground potential differences.

4–20mA uses current as the transmission quantity. Even where a certain voltage drop exists in the line, the loop current can remain relatively stable, making it more suitable for industrial field applications over longer distances. In conventional projects, 4–20mA solutions are generally preferred for pressure signal transmission over distances from tens to hundreds of meters.

Parameter Comparison Table

Interference-Resistance Measures for 4–20mA Pressure Transmitters

4–20mA does not mean that wiring specifications can be ignored. Shielded twisted-pair cable should still be preferred for analog signal lines, and reasonable spacing should be maintained from power cables and variable frequency drive output cables to avoid long parallel cable runs.

Single-end grounding of the shield layer is generally recommended, subject to the control system design requirements. If both ends are repeatedly grounded and a ground potential difference exists on site, an interference loop may instead be formed, resulting in unstable pressure readings.

In high-temperature, high-pressure, high-vibration, or strong electromagnetic environments, in addition to selecting a 4–20mA output, attention should also be given to the transmitter enclosure protection rating, process connection material, diaphragm material, and installation location. Signal format alone cannot solve all on-site issues.

Power Supply and Wiring: How to Choose Between Two-Wire and Three-Wire Systems

4–20mA pressure transmitters commonly use a two-wire system, in which the 24VDC power supply and signal share the same loop. With fewer wires, on-site wiring is simpler, making this arrangement particularly suitable for chemical, energy, water supply, and production line retrofit projects with numerous distributed measurement points.

0–10V pressure transmitters commonly use three-wire or four-wire systems, requiring separate connections for the positive power terminal, negative power terminal, and voltage signal terminal. A reliable common reference terminal must be available between the controller and sensor; otherwise, reading offsets or fluctuations may occur easily.

Regardless of the output type used, the supply voltage should be verified. Common industrial pressure transmitters use 12–36VDC or 24VDC power supplies, but the allowable range, reverse-polarity protection capability, and load requirements vary among models. Product technical documentation should be used as the basis before wiring.

Typical Wiring and System Compatibility

Loop Load Must Not Be Overlooked

A 4–20mA two-wire loop must satisfy the matching relationship among supply voltage, cable voltage drop, and input load. If the total loop load is too high, the transmitter cannot establish the 20mA full-scale current, which may result in lower displayed pressure at the upper end of the range.

For example, when using a 24VDC power supply, the transmitter’s own minimum operating voltage and line voltage drop should be reserved. Long-distance cables, series isolators, display instruments, and PLC input modules all consume loop voltage and should be calculated uniformly during the design stage.

For 0–10V output, input impedance must also be confirmed. If the downstream input impedance is too low, it may pull down the output voltage and cause measurement errors. In principle, multiple devices should not be connected in parallel to one output terminal arbitrarily. A signal isolator or distributor may be used when necessary.

Select According to Operating Conditions to Ensure Long-Term Stable Pressure Measurement

For pressure transmitter selection, the output signal is only one consideration. The measured medium, measuring range, overload capacity, medium temperature, mounting thread, sealing material, accuracy class, and protection rating should also be specified. For example, hydraulic systems often require consideration of pulsating pressure and peak overload, while water treatment systems place greater emphasis on moisture resistance, corrosion resistance, and long-term zero stability.

The recommended range should cover the normal operating pressure while retaining an appropriate margin. Long-term operation near full scale increases the burden on the sensing element, whereas an excessively large range reduces effective resolution. In conventional applications, the range can be determined comprehensively based on the actual maximum operating pressure, surge pressure, and system safety threshold.

Xi’an Shenghongchuang Instrumentation Co., Ltd., supported by the production base of Shaanxi Qinkong Sensor Technology Co., Ltd., can provide selection, customization, and technical services for pressure transmitters and supporting intelligent digital display control instruments, matching measurement and control solutions for applications such as machinery manufacturing, chemical energy, automated production lines, and environmental monitoring.

6 Items Recommended for Confirmation Before Selection

First, clarify whether the pressure type is gauge pressure, absolute pressure, or sealed reference pressure; second, provide the normal pressure, maximum pressure, and potential surge pressure; third, confirm whether the medium is corrosive, viscous, or high-temperature.

Fourth, confirm the process connection specification, such as M20×1.5, G1/4, G1/2, or other interfaces, and verify the sealing method; fifth, confirm whether the system requires 0–10V, 1–5V, 0–5V, or 4–20mA output; sixth, confirm the on-site power supply and controller input type.

When the site involves long-distance transmission, strong interference, outdoor wiring, or centralized control requirements, give priority to evaluating 4–20mA pressure transmitters. When the equipment interface is fixed as a voltage-type input, the wiring distance is short, and environmental interference is low, a 0–10V solution is more direct.

Ensure the Output Signal Truly Matches On-Site Conditions

0–10V does not indicate insufficient performance, nor is 4–20mA suitable for every project. The former is suitable for simple, short-distance equipment integration, while the latter is more suitable for complex industrial sites and long-distance process control. The key is whether it matches the system conditions.

Before project implementation, technical personnel are advised to verify the pressure range, interface dimensions, medium temperature, output signal, power supply method, cable distance, and control-side model to avoid rework caused by incompatible interfaces or signals.

If confirmation is required for the specific model, wiring method, and operating-condition adaptation solution for a 0–10V or 4–20mA pressure transmitter, on-site parameters can be provided for targeted selection and configuration recommendations by professional technical personnel.
